88BlackZ-51 posted this info



88BlackZ-51 posted this info

Postby grumpyvette » June 15th, 2009, 10:59 am

Forged 393 CI:

JE Flat Tops 4.040
Eagle H-Beam 5.85 rods
Eagle 4340 3.750 crank offset ground to 3.830"
0-deck
billet splayed caps
11.2:1 CR
Custom Comps Cam 236/242 .590/.576 112LSA
AFR 195 65cc Eliminator Comp port #1095
T&D Shaft Rockers 1.7/1.6
Ported Edelbrock LT4 intake
58mm Holley TB
42lb Lucas injectors
Be Cool rad 160stat
MSD Optispark/coil/wires
MSD Digital 6 ( yes I plan on spraying )
NGKs FR5
Meizer Electric Water Pump
Exotic Muscle 1 3/4 headers
Corsa Catback 2.5 inch
ARP bolts
Innovative LC-1 Wideband



We are expecting it to trap in the 126-127 mph area.

Enjoy!


IF YOU CAN,T SMOKE THE TIRES AT WILL,FROM A 60 MPH ROLLING START YOUR ENGINE NEEDS MORE WORK!!"!
IF YOU CAN , YOU NEED BETTER TIRES AND YOUR SUSPENSION NEEDS MORE WORK!!
grumpyvette

User avatar
Site Admin
Site Admin

Posts: 14105
Joined: September 14th, 2008, 1:40 pm
Location: florida

Re: 88BlackZ-51 posted this info

Postby grumpyvette » June 15th, 2009, 11:03 am

congrats on a well designed combo!

the only thing Id change that's instantly obvious , in that build, at least to me,would be to get a full length low restriction 3" exhaust with an (X) pipe installed vs the current 2.5" exhaust
IF YOU CAN,T SMOKE THE TIRES AT WILL,FROM A 60 MPH ROLLING START YOUR ENGINE NEEDS MORE WORK!!"!
IF YOU CAN , YOU NEED BETTER TIRES AND YOUR SUSPENSION NEEDS MORE WORK!!
grumpyvette

User avatar
Site Admin
Site Admin

Posts: 14105
Joined: September 14th, 2008, 1:40 pm
Location: florida
